MP:  0BA205.470



Created September 25, 2020



Total Accidents:   3
Crossing DOT #:  350361U
TOTAL DAILY TRAINS:   21   (AS OF 2019)



Page created by: freebrickproductions



This crossing is located on the CSX S&NA North Subdivision.



1

2

3

4

Overviews of the crossing.
The first signal.

5

6

7

8

It has a double-sided WCH base.
An Invensys Rail gate mechanism.
The emergency information.

9

10

11

12

This signal has WCH 12x24 inch lights with WCH 2nd Generation LEDs.
The bell here is an NEG electronic bell.
This signal uses RECO gate lights.

13

14

15

16

The second signal.
It has another double-sided WCH base.

17

18

19

20

A Siemens gate mechanism.
The emergency information.
More WCH 12x24 inch lights with WCH 2nd Generation LEDs over here.

21

22

23

24

This signal has NEG LED gate lights.
The relay case.
Looking southeast towards McDaniel Road near College Grove.
Looking northwest towards Wilson Pike Circle in Brentwood.



All pictures were taken on 5-23-20.
