MP: 705.110 |
Created December 13, 2022
Total Accidents: 0
Crossing
DOT #: 726724D
TOTAL
DAILY TRAINS: 18 (AS OF 2022)
Page created by: freebrickproductions
This crossing is located on the NS East End District.
| >>>>>>>>>>>>> | Signal #1 | Signal #2 |
| Bell: | General Signals electronic | General Signals electronic |
| Base: | Safetran | Safetran |
| Light Frames: | 4 - 12x20" Safetran | 4 - 12x20" Safetran |
| Gate Lights: | 3 - NEG | 3 - NEG |
| Gate Mechanism: | Safetran 2000s | Safetran 2000s |
| Gate Striping: | Vertical | Vertical |
1 |
2 |
3 |
4 |
Overviews of the crossing. |
The first signal. |
||
5 |
6 |
7 |
8 |
It has a Safetran base. |
A Safetran gate mechanism. |
The older and newer emergency information. |
|
9 |
10 |
11 |
12 |
The lights on this signal are all Safetran 12x20 inch lights. |
This signal has a General Signals e-bell. |
This signal uses NEG gate lights. |
|
13 |
14 |
15 |
16 |
The second signal. |
It has another Safetran base. |
Another Safetran gate mechanism. |
|
17 |
18 |
19 |
20 |
The older and newer emergency information. |
The lights on this signal are more Safetran 12x20 inch lights. |
||
21 |
22 |
23 |
24 |
This signal has another General Signals e-bell. |
More NEG gate lights over here. |
The relay case, which has a DOT tag posted on it. |
|
25 |
26 |
Looking west towards CR 66 near Edwardsville. |
Looking northeast towards CR 49 in Muscadine. |
All pictures were taken on 6-30-21.
