MP:  JD48.70



Created June 9, 2016



Total Accidents:   2
Crossing DOT #:  352971J
TOTAL DAILY TRAINS:   2   (AS OF 2016)



Page created by: freebrickproductions



This crossing is located on the HMCR Huntsville Branch.



1	2	3	4
Overviews of the crossing.

5	6	7	8
The crossbuck for Woodson Avenue.	Crossbuck #1 for Clinton Avenue.	Crossbuck for Heart of Huntsville Drive.	Crossbuck #2 for Clinton Avenue.

9	10	11
Relay case with the DOT number and milepost.		Looking north into the HMCR's north yard and towards Holmes Avenue #2. Private Crossing #3 is the next crossing south.



The relay case in pictures 9 and 10 tells the traffic lights at this crossing to all turn red and it also controls the drawf signals around this crossing like the one seen in pictures 9 and 11. It also houses the radio equipment for the crossing, as this crossing is radio-controlled!



All pictures taken 7-20-14.
