MP:  JC49.20



Updated December 13, 2022



Total Accidents:   0
Crossing DOT #:  352978G
TOTAL DAILY TRAINS:   2  (AS OF 2015)



Page created by: freebrickproductions



This crossing is located on the HMCR Huntsville Branch.



1	2	3	4
Overviews of the crossing.		The first signal.

5	6	7	8
It's a Harmon cantilever.	The lights on this signal are all 12x24 inch Harmon lights with Harmon LEDs.

9	10	11	12
		A General Signals Type 2 electronic bell.	The second signal.

13	14	15	16
This signal is the exact same at the other one except for a missing visor.

17

18

19

20

21	22	23	24
The relay case with a DOT tag mounted on it.		Track views. Picture 23 looks south towards Private Crossing #2. Picture 24 looks north towards St. Clair Avenue.

25	26	27	28
In the evening of 2-24-15, a return trip catches the crossing in action.

29	30	31	32
	HMCR 9554 is seen crossing the road in its old CSX MOW paint scheme.

33

34

35

36



Up until December of 2007, this crossing had three mast signals that had a total of 5 pairs of Modern Industries 12x24 inch lights, a single 8 inch light used as an indicator to show the crossing was active, and a US&S Teardrop bell.

However, the city of Huntsville had to widen this road so the old signals were removed and the current ones were installed.









Pictures 1-24 were taken on July 4, 2014.

Pictures 25-36 and the first video were taken on February 24, 2015.

The second video was taken on November 4, 2016.

The third video was taken on December 13, 2018.
