MP: 0WA121.26 |
Updated December 28, 2023
Total Accidents: 3
Crossing
DOT #: 340586W
TOTAL
DAILY TRAINS: 20 (AS OF 2014)
Page created by: freebrickproductions
This crossing is located on the CSX W&A Subdivision.
| >>>>>>>>>>>>> | Signal #1 | Signal #2 |
| Bell: | N/A | Safetran Type 2 electronic |
| Base: | MI | MI |
| Light Frames: | 4 - 12x24" WCH w/ Leotek EV Series LEDs | 4 - 12x24" WCH w/ Leotek EV Series LEDs |
| Gate Lights: | NEG LED | NEG LED |
| Gate Mechanism: | 2000s Safetran | 2000s Safetran |
| Gate Striping: | Vertical | Vertical |
1 |
2 |
3 |
4 |
Overviews of the crossing. |
The first signal. |
It has a Modern Industries base. |
|
5 |
6 |
7 |
8 |
This signal has a US&S/WABCO Model 75 gate mechanism! |
The emergency information. |
This signal has Modern Industries 8 inch lights! |
|
9 |
10 |
11 |
12 |
The gate lights on this signal are from RECO. |
The second signal. |
It has another Modern Industries base. |
|
13 |
14 |
15 |
16 |
This signal has a Safetran gate mechanism. |
The lights on this signal are a mixture of Modern Industries and WRRS 8 inch lights! |
||
17 |
18 |
19 |
20 |
The emergency information. |
This signal has a Safetran Type-2 electronic bell. |
More RECO gate lights over here. |
The relay case. |
21 |
22 |
Track view looking south. |
Track view looking north towards the Tennessee State Line and Julian Road in Chattanooga, TN. |
23 |
24 |
A return trip to the crossing on 9-23-23 finds that it has been upgraded to LED. |
|
25 |
26 |
27 |
28 |
29 |
30 |
The updated first signal. This one also had the Model 75 gate mech on it replaced with another Safetran one, and got a new set of NEG LED gate lights. |
|||
31 |
32 |
33 |
34 |
35 |
The updated second signal. This one also had the gate lights replaced with NEG LEDs. |
||
36 |
37 |
Looking southeast towards Graysville Road. |
Looking northwest towards Julian Road in Chattanooga, TN. |
38 |
39 |
North End Graysville Siding is located on the Tennessee state line just northwest of the crossing. |
An action shot, which I managed to accidentally get when the crossing briefly malfunctioned while I was here. |
Pictures 1-22 were taken on 10-8-16.
The video was taken by Elliot Hammerstone on 6-30-21.
Pictures 23-39 were taken on 9-23-23.
