30.58


190400P

>>>>>>>>>>>>>> Northern Signal Southern Signal
Bell: None GS Type 2 E Bell
Base: Harmon Double Sided Safetran Single Sided
LED Types: Four Harmon Fading LEDs Three Harmon Fading LEDs
One Electro-Tech's LED
Light Frames: Four 12"x24" Harmon frames Three 12"x24" Harmon frames
One 12"x24" Hawker Safetran frame
Junction Box: Harmon Harmon
Gate Lights: NEG Clear LEDs NEG Clear LEDs
Gate Mechanism: WCH Style 3.5 WCH Style 3.5
Gate Saver: GSI Gate Saver GSI Gate Saver
Gate Striping: |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Crossbuck font: NEG, double sided NEG, double sided
Bell Cycle: N/A Rings for the whole duration

All pictures were taken on June 23, 2020, by Tommy McGowan.
The video was taken on June 24, 2020, by Tommy McGowan.
This crossing is located on the UP Clinton Sub.

1
2
Overview of 2 gated signals facing south. Overview facing north.
3 4 5
6 7 8
9 10 11
The northern signal.
12 13 14
15 16 17
18 19 20
21
The southern signal.
22 23 24 25
The relay bungalow in the southeast quadrant. The grade is all concrete. Track view facing west at 1st Ave. Track view facing east towards 190th Ave.
