Western Signal
Eastern Signal
Bell:None
NEG E Bell
Base: WCH Double Sided
WCH Double Sided
LED Types: Four Leotek EV LEDs Four Leotek EV LEDs
Light Frames: Four 12"x24" WCH frames Four 12"x24" WCH frames
Junction Box: WCH
WCH w/ Bell Extension
Gate Lights: 4" NEG LEDs
4" NEG LEDs
Gate Mechanism: Siemens Sticker Style 2
Siemens Sticker Style 2
Gate Striping: |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Crossbuck font:
Normal font
Normal font
Bell Cycle: N/A
Rings only while the gates are lowering

All pictures were taken on April 8, 2017, by Tommy McGowan.
The video was taken on August 14, 2017, by Tommy McGowan.
This crossing is located on the CSX Toledo Sub.

These signals were installed sometime between April 2016 and April 2017 replacing a pair of crossbuck.

1
2
Overview of 2 new gated signals facing east.
Overview facing west.
3 4 5
6 7 8
9 10 11
The western signal.
12 13 14
15 16 17
18 19 20
21
The eastern signal.  The missing visor was fixed by August.
22 23 24 25
The relay bungalow in the northwest quadrant.
The grade is wood and asphalt.
Track view facing north towards Marion St.
Track view facing south towards Road 3 #2.
